VIBRATING SCREEN PANELS

Rubber Self-Cleaning Screen

Rubber Self-Cleaning Screen

Description Inquire
Description

The rubber self-cleaning screen uses rubber imported from Thailand. The composite rubber greatly improves wear resistance and stability. It can be applied to various Vibrating Screen machines, according to user feedback, the service life is 5-10 times that of metal mesh and more wear-resistant than Polyurethane Screen. And it has a better screening effect during the dry screening process.

Specification



Product Name Rubber Self-Cleaning Screen
Screen Size 1, 1.25m width, the length could be customized
Thickness Normally 6 mm, 8 mm could be customized
Aperture Shape Normally round shape, the rectangle shape could be customized
Aperture Size Normally 4-12 mm, the minimum could be made to 3 mm.
Raw Material Rubber imported from Thailand
Installation Method Hook installation



 Advantages

1. Greatly improves wear resistance and stability.
2. The service life is 5-10 times that of metal mesh and more wear-resistant than PU Panel.
3. Better screening effect during the dry screening process.
4. Greatly improved the short life of blocking materials.

Application

Rubber self-cleaning screen is widely used in mining, industrial mineral processing, quarry, and other aggregate screening.
