HT series magnetic separator application:
1. Coarse-grained weak magnetic minerals (hematite, limonite, manganese ore, etc.) coarse-grained tailing or selective purification.
2. Remove the weak magnetic harmful impurities in various refractory materials and other materials.
Structural features of HT series magnetic separator:
The interior adopts a unique magnetic circuit design, using high-performance permanent magnet king NdFeB material as the magnetic source, with strong magnetic field, large suction, high iron removal rate, maintenance-free, energy saving, safe and reliable use, etc.
HT series magnetic separator performance characteristics:
1. Adopt new magnetic system structure, high magnetic field strength (11000-18000GS), high magnetic field gradient (280A/㎡).
2. There is no air gap, the material is not blocked, and the sorting efficiency is high.
3. The selected particle size can be up to 10mm.
4. The magnetic roller is protected and difficult to demagnetize.
5. The installation, maintenance and production and operation costs are low, and the operation is simple.
|
Type |
Cylinder diameter（mm） |
Cylinder length（mm） |
Cylinder qty |
Magnetic induction (GS) |
Selected material particle size (mm) |
Productivity (t/h) |
Motor power（kw） |
Machine size |
weight（kg） |
|
CX1-60AA |
100 |
600 |
1 |
11000-18000 |
0.5-10 |
1-1.5 |
MB0.75KW-C |
1320*880*1270 |
210 |
|
CX2-60AA |
Top roll320 |
600 |
2 |
3500-5000 |
0.5-10 |
1-1.5 |
MB1.5KW-C |
1530*910*1600 |
480 |
|
|
bottom roll100 |
|
|
11000-18000 |
|
|
|
|
|
|
CX2-80AA |
top roll320 |
800 |
2 |
3500-5000 |
0.5-10 |
1.5-2.5 |
MB1.5KW-C |
1530*1110*1630 |
550 |
|
|
bottom roll100 |
|
|
11000-18000 |
|
|
|
|
|
|
CX2-100AA |
top roll320 |
1000 |
2 |
3500-5000 |
0.5-10 |
2-3.5 |
MB1.5KW-C |
1530*1310*1650 |
780 |
|
|
bottom roll100 |
|
|
11000-18000 |
|
|
|
|
|
|
CX3-100AA |
top roll320 |
1000 |
3 |
3500-5000 |
0.5-10 |
2-3.5 |
MB1.5KW×2-C |
1530*1310*2200 |
880 |
|
|
中辊320 |
|
|
3500-5000 |
|
|
|
|
|
|
|
bottom roll100 |
|
|
11000-18000 |
|
|
|
|
|
|
CX3-120AA |
top roll320 |
1200 |
3 |
3500-5000 |
0.5-10 |
2-5 |
MB1.5KW×3-C |
1800*1400*2200 |
950 |
