HT series fine powder magnetic separator application:
It is widely used in the screening of ferromagnetic substances in abrasives, refractory materials, ceramics, chemicals and other materials.
Performance characteristics of HT series fine powder magnetic separator:
The interior adopts a unique magnetic circuit design, using high-performance permanent magnet king NdFeB material as the magnetic source, with strong magnetic field, large suction, high iron removal rate, maintenance-free, energy saving, safe and reliable use, etc.
|
Type |
Cylinder diameter （mm） |
Cylinder length mm） |
Cylinder length |
Magnetic induction (GS) |
Selected material particle size (mm) |
Productivity (t/h) |
Motor power（kw） |
Machien size |
weight（kg） |
|
HT1-60 |
320 |
600 |
1 |
3500-5000 |
power |
0.5-0.8 |
MB07-0.75KW-C |
1070*1510*1100 |
210 |
|
HT2-60 |
320 |
600 |
2 |
3500-5000 |
power |
0.5-0.8 |
MB15-1.5KW-C |
1330*1550*1660 |
450 |
|
HT2-80 |
320 |
800 |
2 |
3500-5000 |
power |
1-1.5 |
MB15-1.5KW-C2 |
1330*1550*1660 |
880 |
|
HT2-120 |
320 |
1200 |
2 |
3500-9000 |
power |
1.5—3t |
1.5kw*2 |
1800*1550*1660 |
950 |
